Maxi reflex

Everything gets bigger, even the emotions you can evoke, with Maxireflex open cell ceiling: same exclusive design and lighting quality as Reflex but in a maxi size to deliver an architectural effect of pure majesty.

Maxireflex's V-shaped parabolic profiles reach 100 millimeters in height; the cell grid is correspondingly larger as well as the surface area of each panel. The result is a sense of regal grandeur that is highlighted by the premium finishes (polished or gold-tinted anodic oxidation, antiridescent with a polished or satin surface) and the lighting, which is, as never before, free to find an unleashed outlet.

Maxireflex panels are in fact able to maximize the performance of light sources, both artificial and natural. That is why you can apply this solution as a continuous ceiling in shopping malls, libraries, showrooms, conference rooms and so on, or use the panels as a simple grid to shield – with a stylish touch – existing simple or channeled light sources from which you want to obtain glare-free light flow.

With the Reflex suspension system, the ceiling panels are installed seamlessly on extruded T-profiles, ensuring you simple and fast installation and removal operations. Alternatively, you can also choose the Delta suspension system, with swing-down demounting.

Details
SUPPLY FORM
Assembled panels
MATERIAL
0,40 mm th. aluminium
SECTION BLADE
SYSTEM INTEGRATED – SWING-DOWN & FREE-FLOATING
SECTION BLADE
“V”, h 100 mm
CELL SIZE
…x… mm
PANEL SIZE
1200x1200 mm (standard)
FINISH
...
SUSPENSION
Delta type, type “B”
QUANTITY
… m2

Gallery

technical details

FEATURES

Maxi Reflex features 1200×1200 mm modular panels, made of “V” profiles 100 mm high, which suitably assembled form a square cell.
Cell size from 100×100 up to 250×250 mm.
Height 100 mm. Upon request, special modules and cell sizes are available.
The Maxi Reflex blades are made by bending system, which gives: the accuracy of profiles, more square edges and blades perfectly straight.
Maxi Reflex is usually supplied in anti-iridescent semi-specular anodised aluminium or gold finish.
Upon request, a wide range of finishes either from pre-painted or post-painted aluminium is also available, according to the RAL, NCS, PANTONE and SIKKENS colours.

LIGHTING SYSTEM

Maxi Reflex excludes any glare, both direct and indirect.
The special paraboliticity of the grill prevents the direct glare and the reflection of lighting on the ceiling surface.
Thanks to its lighting technology, Maxi Reflex has the double effect of a diffuser for artificial lighting and a diffuser for natural light, with energy saving.

SUPPLY FORM

Maxi Reflex is always supplied assembled.

FIRE REACTION

CEIR ceilings are classified as “non-combustible” according to international standards.
Euroclass A1
Euroclass A2-s1, d0 for the post-painted version.

INSTALLATION

With the ceiling system solutions designed from CEIR for Maxi Reflex, designers and architects can define their projects while producing a wholly unique design and in a simple way.
Available:
– trackless solutions: Delta, Type B system Choose the installation system that meets your needs.

FINISHES
MATERIALS AND COLORS

Alu / Steel
CUSTOM RAL/NCS
Alu / Steel
WOOD
Alu / Steel
FLUO EFFECT
